1.2MWH-2.89MWH On-Grid Liquid Cooling BESS Container Storage Energy System
1.2–2.89 MWh On-Grid Liquid Cooling BESS Container ke{3}}mosebetsi o sebetsang hantle oa polokelo ea matla o etselitsoeng marang-rang-litšebeliso tse hokahaneng tsa indasteri le khoebo. The-seseteme e kopaneng, e nang le lik'hontheinara e nolofatsa ts'ebetso, e khutsufatsa nako ea ts'ebetso, 'me e fokotsa kakaretso ea litšenyehelo tsa morero.
Mokelikeli o bohlale o pholisa o boloka lithempereichara tse tsitsitseng tsa betri, ha karolo e meraro{0}} ea BMS e netefatsa hore motho o lula a lekola le ho sebetsa hantle. EMS e kopanetsweng e tshehetsa mefuta e mengata ya tshebetso, e o thusa ho kaonefatsa tshebediso ya motlakase, ho matlafatsa botsitso ba grid, le ho hodisa{2}}lekeno la nako e telele.
Tlhaloso
|
Mohlala
|
KEKETSO
|
|
625/1205 750/1446 875/1688 1000/1929 1125/2170 1250/2411 1375/2652 1500/2893
|
|
|
Kopo
|
Ho-grid
|
|
Li-parameter tsa betri
|
|
|
Mofuta oa Lisele
|
LFP 3.2V/314Ah
|
|
Module ea betri
|
48S1P/48.23kWh
|
|
Tlhophiso ea Sistimi
|
240S5P 240S6P 240S7P 240S8P 240S9P 240S10P 240S11P 240S12P
|
|
Rated Voltage
|
768V
|
|
Range ea Voltage
|
648~864V
|
|
Matla a Sisteme
|
1205.76kWh 1446.91kWh 1688.06kWh 1929.21kWh 2170.36kWh 2411.52kWh 2652.67kWh 2893.82kWh
|
|
Tefiso/Sekhahla sa ho Lahla
|
0.5P
|
|
Cycle Life
|
7000
|
|
AC Output Parameters
|
|
|
Rated Power
|
625kW 750kW 875kW 1000kW 1125kW 1250kW 1375kW 1500kW
|
|
Rated Voltage
|
400V
|
|
E lekantsoe Hona Joale
|
181A*5 181A*6 181A*7 181A*8 181A*9 181A*10 181A*11 181A*12
|
|
Maqhubu a Tshebetso
|
50Hz/60Hz
|
|
Ntho e Matla
|
0.9E etellang pele ~ 0.9 Lagging
|
|
Litsamaiso tsa tsamaiso
|
|
|
Ts'ebetso ea Tsamaiso
|
88%
|
|
Tsamaiso ea Mocheso
|
Mokelikeli-o pholileng
|
|
Sistimi ea Tšireletso ea Mollo
|
Aerosol/Perfluorohexanone
|
|
Mocheso oa ho sebetsa
|
-20~{1}}℃(＞45℃Derating)
|
|
Mongobo o sebetsang
|
0~95% (ha e{2}}ba koaleha)
|
|
Lerata la Tshebetso
|
Ka tlase ho kapa ho lekana le 75 dB(A) @3 m
|
|
Max. Bophahamo ba Tshebetso
|
4000m (＞2000m Derating)
|
|
Tšireletso ea Ingress
|
IP54
|
|
Mokhoa oa Puisano
|
Ethernet
|
|
Boima ba 'mele
|
17T 21T 23T 24T 25T 26T 28T 30T
|
|
Litekanyo(L*W*H)
|
6058*2438*2896mm
|
|
Melao ea Setifikeiti
|
UN38.3,MSDS,IEC 62619,EN 62477,IEC 62933-5-2,EN IEC 61000-6-2/4,G99,VDE-AR-N
4105,VDE-AR-N 4110/4120,EN 50549-1/10,EN 50549-2/10,C10/11,NRS 097-2-1,IEC 62116/IEC
61727,TOR,UNE 217001,UNE 217002,NTS 631-A,NTS 631-B
|
Boemo ba paramente ea mantlha
Bokhoni ba Polokelo ea Matla: 1.2 MWh - 2.89 MWh
Mofuta: Grid{0}}e tlameletsoe
Mokhoa oa ho Pholisa: Pholiso ea Mokelikeli
Mofuta oa Kakaretso: E kentsoeng ka har'a linkho
Tlhophiso ea sistimi ea ts'ireletso ea mollo
| Mofuta oa Tšireletso ea Mollo | Likaroloana | Scenarios tse sebetsang |
|---|---|---|
| Aerosol | Hloekileng, ha ho masalla | Libaka tse tiisitsoeng |
| Phofo e omileng | Tšireletso ea tikoloho, ho kenya letsoho hantle | Thepa{0}} tsa boleng bo holimo |
| Khase (mohlala, IG-541) | Molumo o monyane, nako e telele ea polokelo | Libaka tse thata |
| Moholi oa Metsi / Moholi oa Metsi o Hlahla-Fine Water Mist | Phello e ntle ea ho pholisa | Maemo a hlokang taolo ea mocheso |
Sebopeho sa Sisteme le Likaroloana
Module ea betri
- Module ka 'ngoe e na le lisele tse ngata tsa betri.
- Lisele tsa betri le pakete ea betri li na le mekhahlelo e mengata ea tšireletso.
- E sebelisa lisebelisoa tsa betri tsa lithium iron phosphate (LiFePO4) ho netefatsa matla a tsitsitseng le a nako e telele{1}.
01
Sistimi ea Pholiso ea Mokelikeli
- Mokelikeli o futhumatsang poleiti, liphaephe, pompo, le mochini o futhumatsang mocheso
- Li-sensor tsa mocheso li kopantsoe le BMS bakeng sa taolo le taolo
02
Inverter / Matla a ho Fetola Sistimi
- E fetolela hona joale (DC) hore e be alternating current (AC) bakeng sa khokahanyo ea marang-rang.
- E tšehetsa phallo ea matla a mahlakore a mabeli (ho tjhaja le ho tjhaja).
03
Sistimi ea Taolo
- BMS + EMS (Sistimi ea Taolo ea Matla)
- Kemiso ea matla, taolo ea SOC, ho leka-lekanya matla
04
Sebaka sa setshelo
Setshelo se tloaelehileng sa maoto a 20 / 40-maoto
Lintlha tse thibelang pula, tse thibelang lerole, le tse thibelang mollo{0}} li ka khethoa ka tsela e itseng
Kenyo e suthehang kapa e tsitsitseng
05
Leano la tlhophiso ea bokhoni
1.2 MWh Mohlala oa Tlhophiso:
- Palo ea lihlopha tsa betri: lihlopha tse 10
- Bokhoni ka sehlopha ka seng: 120 kWh
- Voltage ka sehlopha: 768V (240S1P)
- Matla a PCS: 500 kW
2.89 MWh Mohlala oa Tlhophiso:
- Palo ea lihlopha tsa betri: lihlopha tse 20
- Bokhoni ka sehlopha ka seng: 145 kWh
- Voltage ka sehlopha: 1024V (320S1P)
- Matla a PCS: 1.25 MW
Ke hobane'ng ha u re khetha?
Matla a Matla a Phahameng: Sistimi ea ho pholisa metsi e eketsa matla a matla haholo.
Katoloso ea Modular: Bokhoni le matla li ka fetoloa ho latela tlhoko.
Nako e telele ea bophelo le ho senyeha ho tlase: E ts'ehetsa lilemo tsa ts'ebeliso ea cyclic ka litšenyehelo tse tlase tsa tlhokomelo.
Lipalangoang tse Loketseng le ho Kenya: Moralo o tloaelehileng oa lijana bakeng sa ho romelloa ka potlako.
Maemo a mangata a Kopo: Taolo ea Photovoltaic, ho kuta tlhōrō ea mojaro, matla a ho boloka, li-microgrid, joalo-joalo.
Tlhokomelo e Bohlale: Tlhokomelo ea remoutu, ho fumana lintlha, le taolo ea temoso ea pele.
Pholiso ea metsi vs. papiso ea ho pholisa moea
| Papiso Ntho | Sistimi ea Pholiso ea Mokelikeli | Mokhoa oa ho futhumatsa moea |
|---|---|---|
| Katleho ea ho Fetola Mocheso | Holimo (bokhoni bo boholo ba ho senya mocheso) | Mahareng |
| Mocheso o tšoanang | ± 2 likhato | ± 5 likhato |
| Boemo ba Lerata | Tlase (<65dB) | High (>75dB) |
| Tšebeliso ea Matla | E batla e le tlase | E phahameng haholo |
| Molumo oa Sistimi | Compact | E kholoanyane |
| Bophelo ba Battery | E atolositsoe 10-20% | Molemo ka ho fetisisa |
| Litšenyehelo tsa Pele | E phahameng haholo | E batla e le tlase |
| Tlhokomelo e rarahaneng | Mahareng | Tlase |
Karohano ea litšenyehelo tsa sistimi
████████████████████████████Sistimi ea Battery 55%
████████████Sisteme ea PCS 20%
██████ Sistimi ea Taolo ea Mocheso 10%
████Sistimi ea BMS 5%
███Kopanyo/Setshelo 5%
██Tse ling (Tshireletso / Tlhokomelo ea Mollo, joalo-joalo) 5%
Maemo a Kopo
Grid-bobolokelo ba matla bo hokahaneng
Taolo ea matla a tsosolositsoeng
Microgrid le ho tima{0}}motlakase oa bekapo oa grid
Peak ho kuta le ho fetola mojaro
Mekhoa ea ntlafatso ea theknoloji
| Tloaelo | Tlhaloso |
|---|---|
| Bokhoni bo boholo | Bokhoni ba sejana se le seng bo ntse bo hola ho fihla ho 5MWh+ |
| Matla a Phahameng | Sistimi ea 1500V e fetoha ea mantlha |
| Bohlale | Ntlafatso ea AI, tlhokomelo e boletsoeng esale pele |
| Modularization | Tlanya-'me-u bapale, 'me u romeloe ka potlako |
| Bophelo Bolelele | 10000+ lipotoloho li fetoha sepheo |
Ka lebaka la theknoloji ea eona e ntseng e hola ea ho pholisa metsi, tlhahlobo e bohlale, le moralo oa modular, sistimi ena ea BESS ha e kopane feela le grid ea motlakase le litlhoko tsa ts'ebeliso ea indasteri empa hape e fana ka ts'ehetso e tšepahalang bakeng sa ntlafatso ea bokhoni ba nako e tlang le ho ntlafatsa matla, ho thusa lik'hamphani ho fihlela lipheo tsa bona tsa taolo ea matla.
